HOME > Granulation equipment
Capacity：50-1000kg/h
Feed size：
Outsize：
Application：Wood chips, branches, straw, bamboo chips, bagasse, peanut shells, alfalfa, rice husks, coconut shells, EFB palm fibers, etc
Small flat die granulator is one of our main products, also known as flat die granulator. The small machine is easy to operate and suitable for home use. After years of technical improvement, it is very suitable for making wood chips for burning, pellets, high output, and energy efficiency. Low consumption and easy operation.
Model | Power(kw) | Yield（kg/h) | Dimension(m) | Weight(t） |
ZS200 | 7.5 | 50-80 | 1*0.44*1 | 0.4 |
ZS250 | 15 | 100-200 | 1.12*0.44*1.06 | 0.6 |
ZS300 | 22 | 150-250 | 1.28*0.55*1.2 | 0.8 |
ZS350 | 30-4 | 300-400 | 1.3*0.53*1.2 | 0.9 |
ZS400 | 37-4 | 400-500 | 1.4*0.6*1.5 | 1.2 |
ZS450a | 45-4 | 600-800 | 1.62*0.69*1.6 | 1.5 |
ZS450b | 55-4 | 900-1000 | 1.7*0.69*1.6 | 1.6 |
Note: Including electric control, oil pump | ||||
