Swing sieve square

Product Introduction: The square swing screen adopts a hanging structure, which is an efficient screening equipment with high precision and large output. Users can complete the screening needs of different materials within a certain range by increasing or decreasing the spindle speed and excitation force during use. This screening machine adopts a fully enclosed structure, and the screen mesh is usually fixed by tension on both sides, which is easy to install. It is usually designed for 3-8 layers and can screen 6 or 4 types of materials at once. It can also be installed with one layer of screen mesh for use.

Advantages: Technology in the field of dry powder screening, high-efficiency screening equipment with high precision and large output

Product features:

1. Reasonable design, simple structure, and smooth operation;

2. Each layer of screen has a screen anti clogging cleaning device, and the screening machine continuously cleans the screen under working conditions, ensuring that the screen does not block the holes and extending the operating cycle;

3. Good sealing effect, low noise, no dust, improving the working environment of the workshop;

4. The reciprocating rotary motion method quickly disperses and screens materials;

5. No vertical vibration, minimal dynamic load on the foundation, and long lifespan of the screen mesh

Working principle: After the square swing screen is started, the shaking body of the screen machine, that is, the screen box, moves back and forth under the action of inertia force. The screen box drives the screen surface to shake periodically, so that the material on the screen surface moves in a directional jumping motion together with the screen box. During this period, the physical material smaller than the screen surface aperture falls to the lower layer through the screen aperture, becoming the undersized material. The material larger than the screen aperture is discharged from the discharge port after continuous rolling and jumping motion, thus completing the screening work

1. No vertical vibration, minimal dynamic load on the foundation, and long lifespan of the sieve (6-12 months)

2. Each layer of the screen is equipped with a screen anti blocking cleaning device. The screening machine continuously cleans the screen during operation, ensuring that the screen does not block the holes and extending the operating cycle;

3. Due to the use of the principle of planar rotation, the distribution of materials has been significantly improved, thereby increasing the effective utilization rate of the screening surface, ultimately improving the screening efficiency, and reducing the powder content in the finished materials;

4. The fully enclosed structure has no dust pollution and effectively improves the working environment of the workshop.

Reference number of contents:

Grain granules:

Oat kernels 14 mesh Cassia seeds 16 mesh Corn flakes 16 mesh Rice 12-14 mesh Black beans 5 mesh Red beans 5 mesh Soybeans 6 mesh Coix seed 8 mesh Green beans 10 mesh Buckwheat 12 mesh Black rice 14 mesh Brown rice 14 mesh Sesame seeds 24 mesh Xiaomi 24 mesh

Powders: 60 meshes of traditional Chinese medicine powder, roughly 40 months, 60-80 meshes of fine traditional Chinese medicine facial mask, 100-120 meshes of fried chicken wrapping powder, 10-30 meshes of corn powder, 30 meshes of almond powder, 30-40 meshes of flour, 50-60 meshes of intestines powder, 60 meshes of cereal grains, 30-40 meshes of sanqi powder, 80-100 meshes of pearl powder, 120-150 meshes of pine pollen, 80-120 meshes of coffee powder, 100-120 meshes

Liquid type:

Filtered soybean milk, honey 60-120 mesh filtered medicine residue, soup residue, tea water 80-150 mesh

Other categories:

Sichuan pepper 6 mesh insect feces sieve 30 mesh cat litter 30-40 mesh butterfly noodles 50 mesh chili seeds 8-10 mesh sand painting 80-120 mesh edible oil, mechanical oil residue 150-200 mesh yellow mealworm egg laying sieve 12 mesh

Scope of application: Chemical, metallurgical, non-ferrous metal, non-ferrous metal, food, abrasive and other industries.

Applicable materials: mineral products, building materials, quartz sand, various powders, granular materials such as salt, feed, urea, heavy alkali, ceramic particles, and powder materials for screening operations.
